DELPHINUS SERIES
LED Troffers 2x4
The RLUX Delphinus Series LED Troffers 2x4 is designed to offer a superior efficacy of 130 lm/W. It is an excellent alternative to the traditional fluorescent troffers. The lightweight troffers design easily lays into drop ceilings.
Product Specification
| Wattage | 30W-50W | Efficacy | 130lm/W |
| Size | 2ft x4ft | Power Factor | >0.95 |
| Voltage | 100-277 V, 50/60 Hz | Operating Temperature | -14°F to + 113°F |
| CCT | 3500K-4000K-5000K | CRI | 80 |
| IP Rating | IP20 | Diffuser Type | PC |
| Dimming | 0-10 V | ||
• 130 lm/W, DLC Premium.
• Flicker-free.
• UV Treated PS diffuser for Anti yellowing with time.
• Inputs voltage range: 100-277 V, 50-60Hz.
• CCT: 3500K to 5000K.
• CCT & Power Tunable options are available.
• Dimming and sensor options available.
| Part Number | Fixture Type | Dimming | Wattage | CCT | Voltage | CRI | Internal |
| 8 | XX | D | YYYYW | CC | L | XX | Y |
Nomenclature Description
1. Code "8" denotes Product Series Name, 8= Troffer series;
2. Suffix "XX" can be 02 or 04 denotes luminaires shell Shape and Overall dimension, where 02=2FT X 2FT and 04=4FT X 2FT.
3. Suffix "D" can be "Y" or "N" denotes the dimming function of luminaires, Y = Dimmable, N = Non-dimmable.
4. Suffix "yyyyyy" denotes multiple wattage of luminaires. It can be six numbers followed by W; max. 50W, for example, 504030W= Three kinds of wattage 50W, 40W or 30W.
5. Suffix "C" can be two numbers denotes single LED Color Temperature, for example 50=5000K; or it can be six numbers denotes multiple color temperatures, for example 354050= Three kinds of LED Color Temperatures: 3500K, 4000K or 5000K.
6. Suffix "L" denotes range of input voltage; where L=Low voltage range.
7. Suffix "Y" can be blank or four characters denotes commercial code for marketing purpose.
| Delphinus Series LED Troffers 2x4 | |||||
| Model Number | Wattage | Fixture Dimensions (inch) | Packaging Dimension (inch) | Net Weight (lbs) | Gross Weight (lbs) |
| 804Y504030W354050L | 30W/40W/50W | L x W x H - 47.83 x 23.81 x 3 | L x W x H - 50.39 X 26.96 x 6.69 | 11.46 | 26.23 |
| 804D0030WCCLXXY | 30 W | L x W x H - 47.83 x 23.81 x 3 | L x W x H - 50.39 X 26.96 x 6.69 | 11.46 | 26.23 |
| 804D0040WCCLXXY | 40 W | L x W x H - 47.83 x 23.81 x 3 | L x W x H - 50.39 X 26.96 x 6.69 | 11.46 | 26.23 |
| 804D0050WCCLXXY | 50 W | L x W x H - 47.88 x 23.81 x 3 | L x W x H - 50.39 X 26.96 x 6.69 | 11.46 | 26.23 |
